2 Way NPT Globe Valve with Belimo Actuator

Siemens 2 Way NPT Globe Valve

The Flowrite 599 Series 2 way valves are designed to work with either a pneumatic or electronic actuator with a 3/4 inch (20 mm) stroke. They are available in ANSI Class 250 for normally open or normally closed action.

  • ANSI Leakage Class IV (0.01% of Cv)
  • Cartridge type packing
  • Choice of brass or stainless steel trim
  • Direct coupled universal bonnet
  • Choice to two flow characteristics

Flowrite valves are generally recommended for water, steam, and 50% water glycol solutions.

Belimo Damper Actuators

Belimo damper actuators are easily mounted with VSI damper linkages.

These actuators are available in 24VAC, 120V or 220V, modulating or floating service as well as spring return or non-spring return.

Belimo offers a fail-safe version of larger damper actuators. Fail-safe actuators are a cost-effective alternative to mechanical spring return.

Please contact a VSI representative for additional options.


Product Documentation

TrimValve SizeActuator TypeDocument TypeDownload
Bronze.5" to 2"ModulatingSubmittal DocumentDownload PDF
Bronze.5" to 2"2 PositionSubmittal DocumentDownload PDF
Stainless Steel.5" to 2"ModulatingSubmittal DocumentDownload PDF
Stainless Steel.5" to 2"2 PositionSubmittal DocumentDownload PDF
